The one-button measuring instrument adopts double telecentric high-resolution optical lens, combined with high-precision image analysis algorithm, and integrates the principle of one-button flash measurement. under CNC mode, just press the start button, the instrument can automatically locate the measurement object according to the shape of the workpiece, match the template, measurement evaluation, and report generation, which can truly realise one-button fast and accurate measurement.

In the mechanical parts processing industry, after processing a mechanical part, we need to test the two-dimensional dimensional parameters of the mechanical part to determine whether the product quality is qualified, the traditional means of detection are projectors, calipers and so on, with the progress of technology, one-button measuring instrument to gradually replace the traditional means of detection, as a new measurement solution. One-touch measuring instrument is a new type of image measurement technology.

Here we will look at the difference between the one-button measuring instrument and the traditional measuring tool projector:

Detecting workpieces with a projector can only detect one workpiece at a time, and it is necessary to locate the origin on the operating software, and then carry out certain programming work before you can measure the dimensional data of a workpiece. One-touch measuring instrument can measure multiple workpieces at a time, small micro-workpieces can even measure hundreds of them, as long as in the field of view, a measurement of how many operators have the final say, one-touch measuring instrument does not need to locate the point of origin, and do not need to carry out complex programming. Only in the measurement of the first workpiece to establish a template, and thereafter measure the same workpiece just press the one-button measurement button, you can derive the two-dimensional dimensional parameters of the workpiece, batch measurement of up to 512 simultaneous measurement of the part, greatly enhancing the efficiency of the work!

The accuracy of the projector inspection workpiece is generally around 15μm, which can no longer meet the accuracy requirements of the producers in the modern production and processing process. The measurement accuracy of the one-touch measuring instrument is generally about ± 2μm, up to 1μm, is fully able to meet the producer's requirements for accuracy.

Projectors are bulky instruments, large in shape and volume, weighing up to 50-60kg, which is inconvenient to carry to different workshops for inspection. The volume of the one-touch measuring instrument is lightweight, weighing about 18kg, which can be carried by one person to different workshops and production lines to carry out measurement work, saving time, energy and space.
